Flatbed Transporter

Mining crawler flat trucks utilise compressed air as power to achieve self-propulsion via tracks. The standard vehicle length is less than 3 metres and 0.6 metres in height, allowing for light and small goods to be loaded directly by hand. The transport vehicles can carry large loads, have a high walking speed, a simple structure, flexible operation, and convenient maintenance, making them essential equipment in the underground transportation industry of coal mines.

MPCQL-3.5 MPCQL-4.5 MPCQL-5.5 MPCQL-7 MPCQL-8.5 MPCQL-10

Transporting Ore and Bulk Materials

Heavy Material Hauling: Mining crawler flat trucks are commonly used to transport large volumes of ore, coal, rock, and other bulk materials from mining sites to processing plants or storage areas. The flatbed design allows for the easy loading and unloading of materials, and the crawler tracks provide stability on rough, uneven ground, which is typical in open-pit and underground mines.

Efficient Material Movement: These trucks are capable of handling substantial loads, ensuring that large quantities of mined materials can be moved efficiently, reducing the need for multiple trips and minimizing downtime in mining operations.

Transporting Mining Equipment and Machinery

Heavy Equipment Transport: Mining crawler flat trucks are also used for transporting heavy mining equipment, tools, and machinery across the mining site. This includes transporting excavators, drills, bulldozers, or other large machinery between different operational areas within the mine. Their crawler tracks ensure the vehicles can safely carry heavy loads without risking damage to the equipment or the terrain.

 Site-to-Site Transport: In large mining operations where equipment often needs to be relocated or transferred between mining sites or processing facilities, these trucks offer an efficient solution to move the machinery safely and securely.

Underground Mine Transportation

Navigating Challenging Underground Terrain: In underground mining operations, crawler flat trucks are used to transport materials, equipment, and personnel within tunnels and shafts. The crawler tracks offer superior traction and stability, allowing the trucks to operate efficiently in the confined and uneven conditions of underground mines.

 High Payload Capacity: These trucks are designed to carry significant payloads, making them ideal for transporting both raw materials (like ore) and essential mining equipment, all while withstanding the harsh underground environment.

In modern underground mining, the efficient relocation of large-scale machinery is critical to keeping production on schedule. Mining crawler flatbed trucks, such as those developed by Hebei Fikesen Coal Mine Machinery Manufacturing Co., Ltd., are engineered specifically for transporting heavy loads like mine shearers, hydraulic supports, and oversized drilling components through confined tunnel environments. These vehicles serve as a vital link between surface logistics and underground operations, bridging the gap where conventional wheeled trucks cannot navigate.

The flatbed transporter’s crawler system is its defining mobility advantage. Unlike standard tire-based vehicles, the crawler tracks maintain stable traction on uneven, muddy, or debris-covered surfaces commonly found in underground roadways. This ensures the transporter can maneuver heavy equipment safely without risk of tipping or excessive vibration. The low center of gravity further stabilizes loads, reducing stress on both the cargo and the transporter itself.

Built from high-tensile structural steel, the chassis resists bending and torsional deformation under extreme weight. The flatbed platform is reinforced with crossbeam supports, enabling it to handle dynamic loads during start-stop cycles in steep or narrow tunnel sections. Operators benefit from intuitive mechanical controls and clear sightlines, allowing precise positioning of large machinery in tight working zones.

Drawing on its ISO9001-certified quality system and over 67 intellectual property rights, Fikesen has refined these flatbed transporters to deliver consistent performance in demanding environments. Their design is informed by years of producing complementary mining machinery, from directional drilling rigs to rock loaders, ensuring mechanical compatibility across an entire underground fleet.

For mining companies, the ability to rapidly relocate heavy machinery without dismantling it translates into reduced downtime, fewer labor hours, and improved overall output. In an industry where every minute underground is costly, the crawler flatbed truck’s mobility capabilities make it a cornerstone of efficient mining logistics.

Longevity and ease of upkeep are two of the most important factors influencing the selection of mining transport equipment. Underground conditions are inherently harsh—moisture, dust, temperature fluctuations, and abrasive debris all contribute to wear and tear. Hebei Fikesen’s mining crawler flatbed trucks are designed with these realities in mind, prioritizing structural resilience and maintenance simplicity without sacrificing functionality.

The frame structure uses thick-gauge, corrosion-resistant steel treated with anti-rust coatings to withstand continuous exposure to moisture-laden air and chemically active dust. Welded joints are reinforced, and load-bearing members are over-engineered to handle prolonged exposure to maximum rated loads. Even the crawler track shoes are fabricated from wear-resistant alloys, extending operational life before replacement becomes necessary.

The drivetrain and crawler assembly are designed for quick servicing. Modular gearbox housings and easily accessible lubrication points allow routine inspections to be completed in minimal time. Many components are interchangeable with other mining machinery in Fikesen’s product range, reducing the need for extensive parts inventories on site. This modularity simplifies repairs and allows operators to keep equipment in service longer without delays caused by parts shortages.

Since passing its ISO9001 certification in 2017 and earning recognition as a “specialized, special and new” SME in 2019, Fikesen has incorporated systematic feedback from field operators into its designs. This has resulted in features such as bolt-on platform extensions, removable side railings, and integrated tie-down points—enhancements that not only improve durability but also simplify maintenance routines.

In underground mining, equipment breakdowns can halt entire sections of an operation. By minimizing downtime through robust construction and streamlined service procedures, the crawler flatbed transporter helps maintain continuous production cycles, delivering long-term value far beyond its initial acquisition cost.

Mining operations require flexibility in transporting a wide variety of cargo—ranging from precision drilling equipment to irregularly shaped ventilation ducting. A one-size-fits-all transporter can limit operational efficiency, which is why Hebei Fikesen’s mining crawler flatbed trucks are engineered for adaptability. The platform is designed as a modular base, capable of accommodating multiple load configurations without structural compromise.

For large, stable machinery like hydraulic supports, the flatbed’s reinforced deck offers even weight distribution, preventing stress points that could deform the load or the transporter. For irregular loads, adjustable securing systems—such as removable stanchions, chains, and locking brackets—allow safe transport without excessive shifting during movement. The flatbed can also be configured with detachable ramps, enabling direct loading and unloading of wheeled or tracked equipment.

The crawler undercarriage, optimized for underground mobility, enables the transporter to navigate tight curves, steep inclines, and soft ground without becoming bogged down. This agility makes it suitable not only for hauling heavy machinery but also for delivering repair materials, piping, and other construction supplies to remote tunnel sections. Its simple mechanical interface allows operators to quickly adapt to different load types without extensive retraining.

Fikesen’s long history of manufacturing specialized mining machinery—from bolting rigs to roadway repair machines—ensures that its flatbed transporters are mechanically and dimensionally compatible with other critical underground equipment. The company’s recognition as “Shijiazhuang Mine Drilling Equipment Technology Innovation Center” in 2022 underscores its commitment to developing adaptable, operator-friendly designs.

By combining modular load-handling features with proven crawler mobility, the mining crawler flatbed truck maximizes its utility across diverse underground tasks. This adaptability reduces the need for multiple specialized vehicles, streamlining fleet management and optimizing the use of underground transport resources.

Mark Johnson

Mining Operations Manager, Canada

Fikesen’s flatbed crawler truck has been a game-changer for us in underground mining. It handles heavy hydraulic supports and shearers effortlessly, even in tight tunnels. The crawler tracks give excellent stability on uneven surfaces, making heavy equipment transport safe and efficient every time.

Sophie Dubois

Maintenance Supervisor, France

We’ve operated the Fikesen flatbed transporter for over three years in harsh underground conditions. Its robust steel frame and easy maintenance design minimize downtime. The modular parts system also means repairs are quick and affordable—essential for keeping our project on schedule.

Lars Petersen

Logistics Coordinator, Sweden

This flatbed transporter’s versatility impressed us. Whether hauling bulky drill rigs or construction materials, it adapts quickly with adjustable securing systems and removable rails. It’s become indispensable for our underground logistics, reducing the need for multiple specialized vehicles.

Ana Silva

Project Engineer, Brazil

The crawler-based flatbed truck excels in maneuvering steep inclines and narrow tunnels. Its low center of gravity keeps loads secure and stable, even on rough terrain. We trust Fikesen’s transporter for transporting critical equipment without delays or damage.
